The is the Odroid-N2+, the updated revision of Odroid-N2.
The main changes are:
Increased maximum CPU clock for Quad-core Cortex-A73 from 1.8GHz to 2.4GHz
Increased maximum CPU clock for Dual-core Cortex-A53 from 1.9GHz to 2.0GHz
On-board CR2032 RTC battery backup holder - CR2032 battery is very common and can be purchased easily from local shops
The overall profile is lowered to 29mm from 34mm with the possibility to mount an active cooling fan (sold seperately)
Odroid-N2+ is the new generation of Odroid Single Board Computer (SBC) that is more stable and powerful than the previous boards. This board uses Amlogic S922X as its main CPU which is based on a quad-code ARM Cortex-A73@2.4GHz and a dual-code Cortex-A53@2.0GHz integrated under big.LITTLE architecture together with Mali-G52@846MHz GPU. This board has a large metal heatsink attached at the bottom for better heat dissipation and allow it to run at full speed without thermal throttling making it a quiet and robust computer. To manage the system temperature further, there is a fan power connector on-board. Underneath the heatsink, there are four mounting hole where you can attach the fan. It is an important accessory to consider if are planning to overclock this board.
There are two options that you can choose for the on-board memory - 2GB or 4GB RAM. Just like most other Odroid boards, you can use a micro SD card or an eMMC module as storage.
For power, this board uses a common 5.5mm x 2.1mm DC barrel jack and can be powered with a wider voltage range of 7.5V to 16V. A 12V 2A power supply is recommended.
** BONUS: A CR2032 RTC coin cell battery is included for free (while stock lasts) for all delivery within Peninsular Malaysia. Unfortunately due to air shipping restrictions, we cannot include it for other destinations.
CPU: Amlogic S922X Processor (12nm) Quad-core Cortex-A73(2.4Ghz) and Dual-core Cortex-A53(2.0Ghz). ARMv8-A architecture with Neon and Crypto extensions
GPU: Mali-G52 GPU with 6 x Execution Engines (846Mhz)
Memory
2GB or 4GB DDR4 with 32-bit bus width
Data rate: 2640 MT/s (PC4-21333 grade) 1.2V low power design
Storage
1 x eMMC connector
1 x microSD slot (DS/HS modes up to UHS-I SDR104)
Networking
1 x GbE LAN ports (RJ45, supports 10/100/1000 Mbps) - Realtek RTL8211F (Ethernet transceiver) - LED indicators (Green: 100mbps, Amber: 1000mbps connection)
Optional WiFi USB adapters
Video
1 x HDMI 2.1 (up to 4K@60Hz with HDR, CEC, EDID)
1 x Composite video (3.5mm jack)
Audio
1 x Stereo Audio line-out (3.5mm jack)
1 x HDMI digital output
1 x Optional SPDIF optical output
External I/O
4 x USB 3.0 Host ports (shares one single root hub)
1 x USB 2.0 OTG port for Host or Device mode. (No power input)
1 x Debug serial console (UART)
1 x Peripheral Expansion Header (40-pin, 2.54mm pitch)
2 x DC 5V, 2 x DC 3.3V, 1 x DC 1.8V, 8 x GND - 1 x SPI - 1 x UART - 2 x I2C - 25 x GPIO (Max) - 2 x ADC input (10bit, 1.8V Max) - All 3.3V I/O signal level except for ADC input at max 1.8V.
Other features
On-board RTC(Real Time Clock), IC to keep date and time
On-board CR2032 battery holder for RTC. Battery not included
8MiB SPI Flash for future BIOS implementation
IR receiver for remote controller
Built with a large passive heatsink System
LEDS Indicators: - Red (PWR) - Solid light when DC power is connected - Blue (ALIVE) - Flashing like heartbeat while Kernel is running.
Active Cooling Fan Connector (5V 2-pin) - Optional 80 x 80 mm Active Cooling Fan - Connector (2-pin, 1.25mm pitch)
Power
1 x DC jack : outer (negative) diameter 5.5mm, inner(positive) diameter 2.1mm
DC 7.5V ~ 16V (up to 25W) - DC 12V/2A power adaptor is recommended
